Description
- Live effects canvas
- – 2x outputs up to 4K60 or 4x outputs up to 4K30 each with single mixing PiP or two non-mixing PiPs on a still background
- Video inputs
- – 6x HDMI 2.0 connectors
- Video outputs
- – 4x HDMI 2.0 connectors
- Program output
- – Two UHD @60 PGM or Four UHD @30 / FHD @60 PGM
- Mixers
- – 1 mixer per PGM output
- Keying/Mixing
- – Luma and Chroma on non-mixing PiPs
- Still stores
- – Eight stills, up to 4K each
- Multiviewer
- -1x UHD@60 output with user definable layouts consisting of inputs plus PVW and PGM for each screen
- Expandability
- – Includes Dante Audio option for audio extraction from video sources
